Model:GM-088W

Packaging speed:The design speed 70 bags/min(in relation to the application)

Yield:≥98%

Packing method:rolling film tapes,making bags online

Film material:PE complex film,single layer thickness≤70um

Packaging dimensions:Inserted pads,stickered pads,stacker height≤90mm

Three D size:L6.3m x W1.5m x H2.0m

DW:about 2500KG

Installation power:about 17kw

Power requirement:three-phase,four cables system(A、B、C、PE)，380v/50HZ

Air requirement:input air pressure:0.5-0.8Mpa,air consumption≤300LPM

The full servo driving

By adapting Mitsubishi and Yaskawa motion controlling PLC and general linear servo driving system,it ensured a highly accurate package and stability.

Patented angle line structure

It has been highly proved as the most accurate and stable angle line structure.

Patented opening bags structure

The servo controlled opening bags structure can adapt to different sorts of packaging dimensions,by adjusting the data can achieve a exchange of products.

The shortest rim charge

Under the stable angle line situation,this machine shorten the length of the film rim to only 10mm.

High products packaging dimensions adaption

adjusting the inserted pads and stickered pads,as well as 2mm thickness folded panty liner

Working efficiency

Rolling films placing structure .one for working and another for preparation .it anc achieve the non-stop bonding materials,saves the film exchange time,raise the working efficiency.

Intelligent failure analysis

when the machine breaks and material abnormal operation happens,it gave out relatively failure warning tips
